NanoVNA V2 / S-A-A-2 / S-A-A-V2.2 NanoVNA-V2@groups.io

3GHz Second Generation nanoVNA Vector Network Analyzers

NanoVNA V2 / SAA-2 / S-A-A-V2 /SAA-2N

Discussion and Support Group

Specifications:
Frequency range: 50kHz - 3GHz
System dynamic range (calibrated): 70dB (up to 1.5GHz), 60dB (up to 3GHz)
S11 noise floor (calibrated): -50dB (up to 1.5GHz), -40dB (up to 3GHz)
Sweep rate: 100 points/s
Display: 2.8'', 320 x 240
USB interface: Micro USB
Power: USB, 300mA
Battery connector: JST-XH 2.54mm
Maximum sweep points (on device): 201
Maximum sweep points (USB): 1024
NanoVNA-SAVER and VNA-QT software
Ssupported platforms: Linux, Windows (7+), Mac OS planned







### Hugen's SAA-2N!!! 4 inch  touch display and type-N connectors!!! 3000mAh battery!!!



  • SAA-2N host (inside 3000mAh battery) x 1
  • Micro USB data cable x1
  • 50cm N-type male to male RG142-PUR RF cable x2
  • N-type male calibration kit - OPEN x1
  • N-type male calibration kit - SHORT x1
  • N-type male calibration kit - LOAD x1
  • N-type female to female connector x1
  • Touch screen paddles and lanyard x1
  • EVA storage bag x1
https://www.alibaba.com/product-detail/4-inch-display-SAA-2N-NanoVNA_1600090024861.html

Aliexpress supports Paypal
https://www.aliexpress.com/item/1005001267696890.html?fbclid=IwAR3g_czoaxmAdG4QkSQ1Uu6kpLZ3WEDOKDfLFoMYzpbh0XxSoeWI8JkrGOY


### Hugen's 2.8 inch screen SAA-2 with metal case and better cables

prodcut-image

Buy here:
https://www.alibaba.com/product-detail/Metal-Case-SAA2-NanoVNA-V2-3GHz_1600071961178.html



######  S-A-A-2_2 Produced by nanorfe, in collaboration with OwOComm:

HCXQS in collaboration with OwOComm designed the NanoVNA V2
Purchase via TINDIE: https://www.tindie.com/products/hcxqsgroup/nanovna-v2/





######
 S-A-A-2 Produced by Hugen (creator of nanoVNA-H, nanovna-H4) using published design files
:
